Cabinet

• ● Full-opening door with silicone gaskets and cam latch
• ● Interior lighting recessed clear of workspace
• ● Exterior is painted ESPEC slate blue and gray
• ● Chamber floor designed to be changeable to accommodate different “floor plugs” for vibration systems
  • ● Standard floor plug provided is diaphragm for vertical vibration applications (solid or other floors optional)
  • ● Teflon glides in floor slot make floor replacement very easy
• ● Custom models with vertical and horizontal movement to accommodate the use of combo-base vibration systems available.

Refrigeration and Plenum

• ● Plenum with cooling coil and nichrome wire heaters
• ● ¾ hp blower motors with one-piece stainless steel shafts
• ● Non-CFC cascade refrigeration system using semi-hermetic Copeland Scroll or Discus compressors
• ● Automatic water regulator controls water usage on water-cooled models
• ● Humidity models include steam generator and dehumidification coil

System Controls

• ● Instrumentation console mounted to the right of the door
• ● Three levels of overheat protection including an independent, adjustable sensor
• ● Electrical disconnect switch for main power
• ● Specimen power interlock relay for chamber and sample protection

ESPEC’s New P-300 Programmer/Controller:

• ● Easier to use, with USB functionality, smoother ramping, and energy saving operation
• ● User-friendly touch-screen operation with 6.5" active-matrix color display
• ● Three different ‘constant mode’ settings can be saved for single-setting operation
• ● Store 40 programs, with up to 99 steps each (programs may be written on a PC and uploaded via USB)
• ● The trend-graph display shows a record of setpoints and actual values (operation data can be downloaded as needed, or continually, to USB)
• ● Two time signal relays for automated on/off control of test devices/samples
• ● System alarms are stored in memory for historical review
• ● Built-in timer functions allow the chamber to be started or shut down automatically
• ● Pattern Manager Lite PC software for program editing and datalog viewing/exporting, to support USB functionality
