AC 전원공급기 APS-7000
- · ITEM AC 전원공급기
- · MODEL GW APS-7000
- · BRAND GW INSTEK
- · 사양 저노이즈, 저THD, 고도로 안정화된 전력 출력 등 선형 구조 설계의 전력 특성 낮은 노이즈 요구 사항 또는 스테레오, 비디오 및 오디오 장치 애플리케이션 등을 통해 입력 전력의 제품 개발 및 검증에 이상적
- 주요 특징
- • 4.3-inch TFT-LCD
- • Output capacity : APS-7050(500VA、310Vrms、4.2Arms)；APS-7100 (1000VA、310Vrms、8.4Arms)；APS-7200(2000VA、310Vrms、16.8Arms)；APS-7300 (3000VA、310Vrms、25.2Arms)；Output augmentation by options (0~600Vrms/45~999.9Hz)
- • Low Ripple & Noise
- • Measurement and test functions include VOLT、CURR、PWR、SVA、IPK、IPKH、FREQ、PF、CF
- • Support a small AC current measurement 2mA ~ 35A, Min. resolution 0.01mA(APS- 7050& APS-7100)
- • Reverse Current Alarm Function
- • 10 sets of Sequence function to Edit Output Waveforms/ 10 sets of simulate mode to Rapidly Simulate Transient Power Supply/ 10 sets of Program mode to Define Measurement Sequence/ 10 sets of Panel Memory Function
- • Automatic Execution of Sequence、Simulate、Program mode and Output Function when the Power is on
- • Standard Interfaces: LAN, USB Host, USB Device (APS-7200 and APS-7300 models only)
- • Optional Interfaces: GPIB (APS-001)；RS-232 / USB CDC(APS-002 for APS-7050& APS-7100 only)；RS-232(APS-007 for APS-7200& APS-7300 only)
