주요 특징

• Operating voltage (DC)：PEL-3000H (1.5V~150V), PEL-3000H (5V~800V)

• Operating Mode : C.C / C.V / C.R / C.P / CC+CV / CR+CV / CP+CV

• Parallel Connection of Inputs for Higher Capacity (Max : 9,450W)

• Support of High Slew Rate：Max 16A/us

• Run Program Function（GO/NO GO Test）

• Sequence Function for High Efficient Load Simulations

• Commands are compatible with Kikusui PLZ-4W model.

• Dynamic(Switching) Function：0.0166Hz ~20kHz

• Soft Start Function：Off / On(1~200ms, Res：1ms)

• Adjustable OCP / OVP / OPP / UVP Setting

• Short Circuit Function

• Timer function : Elapsed Time of load on

• Cut Off Time(Auto Load Off Timer )：1s to 999h 59min 59s or Off

• External Channel Control / Monitoring via Analog Control Connector

• Setup Memories：100 sets

• 3.5 Inch TFT LCD Display

• Multi Interface : USB 2.0 Device / Host , RS-232 , GPIB (Optional)
